Garmin Echomap UHD2 65SV with GT54UHD-TM Transducer Fishfinder Sounder 010-02682-20

FREE SHIPPING ON ORDERS OVER $120*

The Garmin Echomap UHD2 65CV sounder combo has everything you need to catch more fish. It features a 6.5 inch easy-to-use touchscreen with a keyed chartplotter for added convenience. The included GT54-TM transducer is simple to install and supports Garmin traditional, ClearVu and SideVu scanning sonars. And for anglers wishing to use LiveScope sonar, this technology is fully supported with a separate transducer (not included).

Garmin vivid colour palettes make it easier than ever to distinguish between bait, fish and structure. The Echomap UHD 65CV also comes with preloaded Navionics+ charts for Australian and NZ coastal and inland waters. Extra features include Garmin marine app connectivity, NMEA 200 compatibility and an in-built multi band GPS. Explore new ground and put more fish in the boat with this compact, highly versatile Garmin sounder.

Garmin Echomap UHD2 65SV with GT54UHD-TM Transducer Fishfinder Sounder Features

Garmin Echomap 65SV Sounder with Transducer

- Easy-to-use touchscreen with keyed assist chart plotter with bright, sunlight-readable screens
- Included GT54-TM transducer for Garmin traditional, ClearVu and SideVu scanning sonars
- Garmin Navionics+™ charts for Australia and New Zealand: Includes HD Bathymetric charts
- Built in WIFI connectivity: Wirelessly share information such as sonar, waypoints and routes. If you have another compatible ECHOMAP UHD2 chartplotter on your boat, you can wirelessly share information — such as sonar1, waypoints and routes — with them.
- Supports wired NMEA 2000 marine network connectivity
- Includes multi-band GPS
- Compatible with LiveScope live scanning sonar
- Vivid scanning sonar colour palettes make it easy to distinguish fish and structure
- ACTIVECAPTAIN® APP: Built-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications2, software updates, Garmin QuickDraw Community data and more.
- Power-Pole® Shallow Water Anchor: By networking select Garmin chartplotters with a Force® trolling motor and your compatible Power-Pole shallow water anchoring system, you can access advanced boat control features4 from your plotter, including smart anchor auto-deployment, smart anchor jog, auto stow, anchor drag detection and auto guidance5 end-of-route anchoring. Spend more time fishing, less time positioning.

Garmin Echomap UHD2 65SV with GT54UHD-TM Transducer Fishfinder Sounder Specifications

- Model: 010-02682-20
- Physical dimensions: 8.1″ x 5.2″ x 2.6″ (20.6 x 13.1 x 6.7 cm)
- Weight: 1.8 lbs (0.8 kg)
- Water rating: IPX7
- Display type: WVGA, TN
- Display resolution: 800 x 480 pixels
- Wireless connectivity: Yes

Maps and Memory

- Accepts data cards: 1 microSD™ card; 32 GB maximum card size
- Waypoints: 5,000
- Routes: 100
- Track log: 50,000 points; 50 saved tracks

Chartplotter Features

- Garmin Sonar compatible: Yes
- Supports AIS (tracks target ships position) Yes
- Supports DSC (displays position data from DSC-capable VHF radio) Yes
- Frequencies supported: CHIRP (low, mid, high) / Traditional: 50/77/83/200 kHz / ClearVü: 260/455/800/1000/1200 kHz
- Transmit power: 500W
- CHIRP sonar technology: Yes (Built-in)
- ClearVü: Yes with CHIRP (built-in)
- SideVü: Yes (bulit-in)

Connections
